Veriti 384-Well Thermal Cycler
A Veriti thermal cycler with a 384-well block for high-throughput PCR workflows.
Read the product overviewVeriti family — closed view; block configuration as specified
Manufacturer brochure / specificationsPDFProduct overview
A Veriti thermal cycler with a 384-well block for high-throughput PCR workflows.
Veriti 384-Well is the high-throughput block configuration in the original Veriti range. It uses a 384-well aluminium block with a colour touchscreen, onboard protocol storage and USB support. The manufacturer specification does not assign VeriFlex zones or Fast-chemistry support to this model; those features must not be carried over from the 96-well versions.
- 384-well block
- Touchscreen protocol management
- USB and onboard storage
Specifications
| Capacity: | 384 x 0.02 mL |
|---|---|
| Notes: | High-throughput, single-block system optimised for small-volume reactions |
| Dimensions: | Height: 24.5 cm; width: 23.7 cm; depth: 48.5 cm |
| Display: | 6.5 in. VGA 32k-colour touchscreen |
| Format: | 384-well plate |
| High-throughput capability: | High-throughput compatible |
| Instrument memory: | USB and onboard memory |
| Block ramp rate: | 3.7°C/second |
| Product line: | Veriti™ |
| Product size: | 1 instrument |
| Program features: | Automatic restart after power interruption; program overwrite protection |
| Reaction speed: | Standard |
| Reaction volume range: | 5-20 µl |
| Sample ramp rate: | ±3.1°C/second |
| Temperature accuracy: | ±0.25°C (35°C to 99.9°C) |
| Temperature range: | 4.0-99.9 °C |
| Temperature uniformity: | <0.5°C (20 seconds after reaching 95°C) |
| Weight: | 11.4 kg (25 lb) |
