Veriti 60-Well Thermal Cycler
A Veriti thermal cycler with a 60-well, 0.5 mL block for larger-volume PCR workflows.
Read the product overviewVeriti family — closed view; block configuration as specified
Manufacturer brochure / specificationsPDFProduct overview
A Veriti thermal cycler with a 60-well, 0.5 mL block for larger-volume PCR workflows.
Veriti 60-Well accommodates 0.5 mL reaction tubes in the original Veriti thermal-cycler range. The system provides touchscreen protocol control, onboard storage and USB support. Its block configuration does not include the VeriFlex zones used by the 96-well versions, and the manufacturer does not list it for Fast chemistry.
- 60-well format
- For 0.5 mL reaction tubes
- Touchscreen and stored protocols
Specifications
| Block format: | Fixed |
|---|---|
| Capacity: | 1 × 60-well × 0.5 mL tubes |
| Notes: | Easy-to-use reaction tubes for large-volume reactions |
| Dimensions: | Height: 24.5 cm; width: 23.7 cm; depth: 48.5 cm |
| Display: | 6.5 in. VGA 32k-colour touchscreen |
| Format: | 0.5 mL tubes |
| Instrument memory: | USB and onboard memory |
| Block ramp rate: | 3.3°C/second |
| Product line: | Veriti™ |
| Product size: | 1 instrument |
| Program features: | Automatic restart after power interruption; program overwrite protection |
| Reaction speed: | Standard |
| Reaction volume range: | 25-100 µl |
| Sample ramp rate: | ±2.7°C/second |
| Temperature accuracy: | ±0.25°C (35°C to 99.9°C) |
| Temperature range: | 4.0-99.9 °C |
| Temperature uniformity: | <0.5°C (20 seconds after reaching 95°C) |
| Weight: | 11.4 kg (25 lb) |
